LPC1768UKZ

Technical Details

• Series:LPC17xx
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Core Processor:ARM® Cortex®-M3
• Core Size:32-Bit
• Speed:100MHz
• Connectivity:CANbus, Ethernet, I²C, IrDA, Microwire, SPI, SSI, UART/USART, USB OTG
• Peripherals:Brown-out Detect/Reset, DMA, I²S, Motor Control PWM, POR, PWM, WDT
• Number of I/O:70
• Program Memory Size:512KB (512K x 8)

• Program Memory Type:FLASH
• EEPROM Size:-
• RAM Size:64K x 8
• Voltage - Supply (Vcc/Vdd):2.4V ~ 3.6V
• Data Converters:A/D 8x12b; D/A 1x10b
• Oscillator Type:Internal
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:100-UFBGA, WLCSP
• Supplier Device Package:100-WLCSP (5.07x5.07)
