UPD78F0566MC-CAA-AX
Renesas Electronics America
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MCU 8BIT 8KB FLASH 20SSOP
- CategoryEmbedded - Microcontrollers
- Datasheet UPD78F0566MC-CAA-AX Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:78K0/Kx2-L
- Package:Tray
- Part Status:Active
- Core Processor:78K/0
- Core Size:8-Bit
- Speed:10MHz
- Connectivity:I²C, LINbus, UART/USART
- Peripherals:LVD, POR, PWM, WDT
- Number of I/O:13
- Program Memory Size:8KB (8K x 8)
- Program Memory Type:FLASH
- EEPROM Size:-
- RAM Size:512 x 8
- Voltage - Supply (Vcc/Vdd):1.8V ~ 5.5V
- Data Converters:A/D 6x10b
- Oscillator Type:Internal
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:20-SSOP (0.209", 5.30mm Width)
- Supplier Device Package:-
