9C-22.1184MAAJ-T
TXC Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCRYSTAL 22.1184MHZ 18PF SMD
- CategoryCrystals
- Datasheet 9C-22.1184MAAJ-T Datasheet
-
ECAD Model
- Share
In Stock: 1,202
Can ship immediately
Pricing:
- 1$0.42
- 1,000$0.224
- 3,000$0.21
- 5,000$0.203
- 10,000$0.196
Quote It
Technical Details
- Series:9C
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:MHz Crystal
- Frequency:22.1184 MHz
- Frequency Stability:±30ppm
- Frequency Tolerance:±30ppm
- Load Capacitance:18pF
- ESR (Equivalent Series Resistance):30 Ohms
- Operating Mode:Fundamental
- Operating Temperature:-20°C ~ 70°C
- Ratings:-
- Mounting Type:Surface Mount
- Package / Case:HC-49/US
- Size / Dimension:0.449" L x 0.189" W (11.40mm x 4.80mm)
- Height - Seated (Max):0.161" (4.10mm)
