CSM4Z-A2B3C3-40-12.0D18
Cardinal Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCRYSTAL 12.0000MHZ 18PF SMD
- CategoryCrystals
- Datasheet CSM4Z-A2B3C3-40-12.0D18 Datasheet
-
ECAD Model
- Share
In Stock: 1,443
Can ship immediately
Pricing:
- 1$0.62
- 1,000$0.37582
- 3,000$0.3553
- 5,000$0.34504
- 10,000$0.33478
Quote It
Technical Details
- Series:CSM4
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:MHz Crystal
- Frequency:12 MHz
- Frequency Stability:±30ppm
- Frequency Tolerance:±30ppm
- Load Capacitance:18pF
- ESR (Equivalent Series Resistance):40 Ohms
- Operating Mode:Fundamental
- Operating Temperature:-40°C ~ 85°C
- Ratings:-
- Mounting Type:Surface Mount
- Package / Case:HC-49S
- Size / Dimension:0.449" L x 0.185" W (11.40mm x 4.70mm)
- Height - Seated (Max):0.138" (3.50mm)
