ABM8AIG-12.000MHZ-2-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCRYSTAL 12.0000MHZ 18PF SMD
- CategoryCrystals
-
ECAD Model
- Share
In Stock: 993
Can ship immediately
Pricing:
- 1$0.82
- 1,000$0.4755
- 3,000$0.45965
- 5,000$0.4438
- 10,000$0.42795
Quote It
Technical Details
- Series:ABM8AIG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:MHz Crystal
- Frequency:12 MHz
- Frequency Stability:±100ppm
- Frequency Tolerance:±20ppm
- Load Capacitance:18pF
- ESR (Equivalent Series Resistance):100 Ohms
- Operating Mode:Fundamental
- Operating Temperature:-40°C ~ 125°C
- Ratings:AEC-Q200
- Mounting Type:Surface Mount
- Package / Case:4-SMD, No Lead
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.031" (0.80mm)
