9B-3.6864MAHK-B
TXC Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCRYSTAL 3.6864MHZ 20PF TH
- CategoryCrystals
- Datasheet 9B-3.6864MAHK-B Datasheet
-
ECAD Model
- Share
In Stock: 112
Can ship immediately
Pricing:
- 1$0.192
- 1,000$0.192
Quote It
Technical Details
- Series:9B
- Package:Bulk
- Part Status:Active
- Type:MHz Crystal
- Frequency:3.6864 MHz
- Frequency Stability:±30ppm
- Frequency Tolerance:±30ppm
- Load Capacitance:20pF
- ESR (Equivalent Series Resistance):150 Ohms
- Operating Mode:Fundamental
- Operating Temperature:-40°C ~ 85°C
- Ratings:-
- Mounting Type:Through Hole
- Package / Case:HC-49/US
- Size / Dimension:0.453" L x 0.197" W (11.50mm x 5.00mm)
- Height - Seated (Max):0.145" (3.68mm)
