AA-13.560MDHE-T
TXC Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCRYSTAL 13.5600MHZ 12PF SMD
- CategoryCrystals
- Datasheet AA-13.560MDHE-T Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$0.48
- 1,000$0.48
Quote It
Technical Details
- Series:AA
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:MHz Crystal
- Frequency:13.56 MHz
- Frequency Stability:±30ppm
- Frequency Tolerance:±20ppm
- Load Capacitance:12pF
- ESR (Equivalent Series Resistance):100 Ohms
- Operating Mode:Fundamental
- Operating Temperature:-40°C ~ 85°C
- Ratings:AEC-Q200
- Mounting Type:Surface Mount
- Package / Case:2-SMD, No Lead
- Size / Dimension:0.197" L x 0.126" W (5.00mm x 3.20mm)
- Height - Seated (Max):0.053" (1.35mm)
