- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCRYSTAL 26MHZ 8PF SMD 2.0X1.6MM
- CategoryCrystals
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$0.43
Quote It
Technical Details
- Series:XT224
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:MHz Crystal
- Frequency:26 MHz
- Frequency Stability:±30ppm
- Frequency Tolerance:±10ppm
- Load Capacitance:8pF
- ESR (Equivalent Series Resistance):100 Ohms
- Operating Mode:Fundamental
- Operating Temperature:-40°C ~ 85°C
- Ratings:-
- Mounting Type:Surface Mount
- Package / Case:4-SMD, No Lead
- Size / Dimension:0.081" L x 0.065" W (2.05mm x 1.65mm)
- Height - Seated (Max):0.020" (0.50mm)
