15-000413
CONEC
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB PLUG 9P PNL MNT SLDR
- CategoryD-Sub Connectors
- Datasheet 15-000413 Datasheet
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$19.17
- 10$17.80223
- 25$15.97599
- 50$15.51943
- 100$13.69361
- 250$12.78071
- 500$12.50683
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Connector Style:D-Sub
- Connector Type:Plug, Male Pins
- Number of Positions:9
- Number of Rows:2
- Mounting Type:Panel Mount, Through Hole
- Shell Size, Connector Layout:1 (DE, E)
- Contact Type:Signal
- Flange Feature:Mating Side, Female Screwlock (4-40)
- Termination:Solder
- Shell Material, Finish:Zinc Die Cast, Nickel Plated
- Contact Finish:Gold
- Contact Finish Thickness:8.00µin (0.203µm)
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):7.5A
- Backset Spacing:-
- Features:Board Lock
