1731130148
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB HD PLUG 26POS PNL MNT
- CategoryD-Sub Connectors
- Datasheet 1731130148 Datasheet
-
ECAD Model
- Share
In Stock: 213
Can ship immediately
Pricing:
- 1$14.56
- 100$10.71
Quote It
Technical Details
- Series:HPD, 173113
- Package:Bulk
- Part Status:Active
- Connector Style:D-Sub, High Density
- Connector Type:Plug, Male Pins
- Number of Positions:26
- Number of Rows:3
- Mounting Type:Panel Mount
- Shell Size, Connector Layout:2 (DA, A) High Density
- Contact Type:Signal
- Flange Feature:Housing/Shell (Unthreaded)
- Termination:Solder Cup
- Shell Material, Finish:Steel, Tin Plated
- Contact Finish:Gold
- Contact Finish Thickness:31.5µin (0.80µm)
- Ingress Protection:IP20
- Material Flammability Rating:-
- Current Rating (Amps):5A
- Backset Spacing:-
- Features:Grounding Indents
