1731130153
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB HD PLUG 15P R/A SLDR
- CategoryD-Sub Connectors
- Datasheet 1731130153 Datasheet
-
ECAD Model
- Share
In Stock: 231
Can ship immediately
Pricing:
- 1$15.11
- 100$11.118
Quote It
Technical Details
- Series:HPD, 173113
- Package:Bulk
- Part Status:Active
- Connector Style:D-Sub, High Density
- Connector Type:Plug, Male Pins
- Number of Positions:15
- Number of Rows:3
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Shell Size, Connector Layout:1 (DE, E) High Density
- Contact Type:Signal
- Flange Feature:Board Side (4-40)
- Termination:Solder
- Shell Material, Finish:Steel, Tin Plated
- Contact Finish:Gold
- Contact Finish Thickness:31.5µin (0.80µm)
- Ingress Protection:IP20
- Material Flammability Rating:-
- Current Rating (Amps):5A
- Backset Spacing:0.314" (7.98mm)
- Features:Board Lock, Grounding Indents, Mounting Brackets
