DBM9W4PD
VEAM- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB PLUG 9POS R/A SLDR
- CategoryD-Sub Connectors
- Datasheet DBM9W4PD Datasheet
-
ECAD Model
- Share
In Stock: 222
Can ship immediately
Pricing:
- 1$18.73
- 5$16.21177
- 10$15.96808
- 25$15.07684
- 50$14.99584
Quote It
Technical Details
- Series:Combo D®, D*M
- Package:Bulk
- Part Status:Active
- Connector Style:D-Sub, Combo
- Connector Type:Plug, Male Pins
- Number of Positions:9 (5 + 4 Coax or Power)
- Number of Rows:2
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Shell Size, Connector Layout:3 (DB, B) - 9W4
- Contact Type:Signal and Coax or Power (Not Included)
- Flange Feature:Housing/Shell (Unthreaded)
- Termination:Solder
- Shell Material, Finish:Steel, Yellow Chromate Plated Zinc
- Contact Finish:Gold
- Contact Finish Thickness:Flash
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):7.5A
- Backset Spacing:-
- Features:Shielded
