684M17W2103L461
NorComp
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB PLUG 17POS R/A SLDR
- CategoryD-Sub Connectors
- Datasheet 684M17W2103L461 Datasheet
-
ECAD Model
- Share
In Stock: 159
Can ship immediately
Pricing:
- 1$14.84
- 10$13.49284
- 25$13.15552
- 50$12.14355
- 100$11.46891
- 250$10.45695
- 500$9.78231
- 1,000$8.97274
Quote It
Technical Details
- Series:Power-D 684M
- Package:Tray
- Part Status:Active
- Connector Style:D-Sub, Combo
- Connector Type:Plug, Male Pins
- Number of Positions:17 (15 + 2 Power)
- Number of Rows:2
- Mounting Type:Board Edge, Through Hole, Right Angle
- Shell Size, Connector Layout:3 (DB, B) - 17W2
- Contact Type:Signal and Power
- Flange Feature:Housing/Shell (4-40)
- Termination:Solder
- Shell Material, Finish:Steel, Nickel Plated
- Contact Finish:Gold
- Contact Finish Thickness:Flash
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):5A, 40A
- Backset Spacing:0.401" (10.20mm)
- Features:Board Lock, Grounding Indents, Mounting Brackets
