09564615712
HARTING
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB HD PLUG 62P VERT SLDR
- CategoryD-Sub Connectors
- Datasheet 09564615712 Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$13.02
- 10$11.83636
- 25$11.54056
- 50$10.65273
- 100$10.06091
- 250$9.1732
- 500$8.58136
- 1,000$7.87118
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Connector Style:D-Sub, High Density
- Connector Type:Plug, Male Pins
- Number of Positions:62
- Number of Rows:3
- Mounting Type:Through Hole
- Shell Size, Connector Layout:4 (DC, C) High Density
- Contact Type:Signal
- Flange Feature:Board Side (4-40)
- Termination:Solder
- Shell Material, Finish:Steel, Nickel Plated
- Contact Finish:Gold or Gold-Palladium
- Contact Finish Thickness:30.0µin (0.76µm)
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):2A
- Backset Spacing:-
- Features:Board Lock, Grounding Indents
