09694115253
HARTING
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB PLUG 25POS SLDR CUP
- CategoryD-Sub Connectors
- Datasheet 09694115253 Datasheet
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$17.43
- 10$16.18108
- 25$14.52169
- 50$14.10658
- 100$12.44698
- 250$11.61718
- 500$11.36825
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Connector Style:D-Sub, Combo
- Connector Type:Plug, Male Pins
- Number of Positions:25 (22 + 3 Coax or Power)
- Number of Rows:2
- Mounting Type:Free Hanging (In-Line)
- Shell Size, Connector Layout:4 (DC, C) - 25W3
- Contact Type:Signal and Coax or Power (Not Included)
- Flange Feature:Housing/Shell (Unthreaded)
- Termination:Solder Cup
- Shell Material, Finish:Steel, Tin Plated
- Contact Finish:Gold or Gold-Palladium
- Contact Finish Thickness:30.0µin (0.76µm)
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):5A
- Backset Spacing:-
- Features:Grounding Indents
