M83513/13-A01CP
Vitelec / Cinch Connectivity Solutions- Lifecycle status Active
- RoHS RoHS Compliant
- Description9 POS RCPT RED. 90 PCB CD PLTD
- CategoryD-Sub Connectors
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
- 1$64.38
Quote It
Technical Details
- Series:Military, MIL-C-83513, M83513
- Package:Bag
- Part Status:Active
- Connector Style:D-Type, Micro-D
- Connector Type:Receptacle, Female Sockets
- Number of Positions:9
- Number of Rows:2
- Mounting Type:Through Hole, Right Angle
- Shell Size, Connector Layout:0.050 Pitch x 0.043 Row to Row
- Contact Type:Signal
- Flange Feature:Mating Side, Female Screwlock (2-56)
- Termination:Solder
- Shell Material, Finish:Aluminum Alloy, Yellow Chromate Plated Cadmium
- Contact Finish:Gold
- Contact Finish Thickness:50.0µin (1.27µm)
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):3A
- Backset Spacing:0.230" (5.84mm)
- Features:-
