634-015-563-042
EDAC Inc.- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB HD RCPT 15P R/A SLDR
- CategoryD-Sub Connectors
- Datasheet 634-015-563-042 Datasheet
-
ECAD Model
- Share
In Stock: 182
Can ship immediately
Pricing:
- 1$4.914
- 50$4.914
Quote It
Technical Details
- Series:634
- Package:Tray
- Part Status:Active
- Connector Style:D-Sub, High Density
- Connector Type:Receptacle, Female Sockets
- Number of Positions:15
- Number of Rows:3
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Shell Size, Connector Layout:1 (DE, E) High Density
- Contact Type:Signal
- Flange Feature:Housing/Shell (4-40)
- Termination:Solder
- Shell Material, Finish:Steel, Nickel Plated
- Contact Finish:Gold
- Contact Finish Thickness:10.0µin (0.25µm)
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):3A
- Backset Spacing:0.350" (8.89mm)
- Features:Board Lock, Shielded
