8309-8009
3M
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB RCPT 9POS PNL MNT IDC
- CategoryD-Sub Connectors
- Datasheet 8309-8009 Datasheet
-
ECAD Model
- Share
In Stock: 117
Can ship immediately
Pricing:
- 1$5.4112
- 200$5.4112
Quote It
Technical Details
- Series:8300
- Package:Bulk
- Part Status:Active
- Connector Style:D-Sub
- Connector Type:Receptacle, Female Sockets
- Number of Positions:9
- Number of Rows:2
- Mounting Type:Panel Mount
- Shell Size, Connector Layout:1 (DE, E)
- Contact Type:Signal
- Flange Feature:Housing/Shell (Unthreaded)
- Termination:IDC, Ribbon Cable
- Shell Material, Finish:Steel, Tin Plated
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):1A
- Backset Spacing:-
- Features:Feed Through
