L77TWA3W3SMP3V4RRM6
Storage & Server IO (Amphenol ICC)- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB RCPT 3POS R/A SLDR
- CategoryD-Sub Connectors
- Datasheet L77TWA3W3SMP3V4RRM6 Datasheet
-
ECAD Model
- Share
In Stock: 122
Can ship immediately
Pricing:
- 1$8.1757
- 200$8.1757
Quote It
Technical Details
- Series:TW
- Package:Tray
- Part Status:Active
- Connector Style:D-Sub, Combo
- Connector Type:Receptacle, Female Sockets
- Number of Positions:3 (Power)
- Number of Rows:1
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Shell Size, Connector Layout:2 (DA, A) - 3W3
- Contact Type:Power
- Flange Feature:Board Side (4-40)
- Termination:Solder
- Shell Material, Finish:Steel, Tin Plated
- Contact Finish:Gold
- Contact Finish Thickness:16.0µin (0.41µm)
- Ingress Protection:-
- Material Flammability Rating:-
- Current Rating (Amps):-
- Backset Spacing:0.845" (21.46mm)
- Features:Board Lock, Mounting Brackets
