DB-25SA-NR
JAE Electronics- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB RCPT 25POS R/A SLDR
- CategoryD-Sub Connectors
- Datasheet DB-25SA-NR Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
- 1$14.19258
- 31$14.19258
Quote It
Technical Details
- Series:-
- Package:-
- Part Status:Active
- Connector Style:D-Sub
- Connector Type:Receptacle, Female Sockets
- Number of Positions:25
- Number of Rows:2
- Mounting Type:Through Hole, Right Angle
- Shell Size, Connector Layout:3 (DB, B)
- Contact Type:Signal
- Flange Feature:Housing/Shell (M2.6)
- Termination:Solder
- Shell Material, Finish:Steel, Zinc Plated
- Contact Finish:Gold
- Contact Finish Thickness:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):5A
- Backset Spacing:0.283" (7.20mm)
- Features:-
