748047-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB RCPT 9POS SLDR CUP
- CategoryD-Sub Connectors
- Datasheet 748047-1 Datasheet
-
ECAD Model
- Share
In Stock: 122
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:AMPLIMITE HD-20
- Package:Bulk
- Part Status:Obsolete
- Connector Style:D-Sub
- Connector Type:Receptacle, Female Sockets
- Number of Positions:9
- Number of Rows:2
- Mounting Type:Free Hanging (In-Line)
- Shell Size, Connector Layout:1 (DE, E)
- Contact Type:Signal
- Flange Feature:Cable Side, Male Jackscrew (4-40)
- Termination:Solder Cup
- Shell Material, Finish:Steel, Tin Plated
- Contact Finish:Gold
- Contact Finish Thickness:Flash
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):3A
- Backset Spacing:-
- Features:Backshell, Cover, Mounting Hardware, Shielded
