745782-6
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB RCPT 15POS R/A SLDR
- CategoryD-Sub Connectors
- Datasheet 745782-6 Datasheet
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:AMPLIMITE HD-20
- Package:Tray
- Part Status:Obsolete
- Connector Style:D-Sub
- Connector Type:Receptacle, Female Sockets
- Number of Positions:15
- Number of Rows:2
- Mounting Type:Through Hole, Right Angle
- Shell Size, Connector Layout:2 (DA, A)
- Contact Type:Signal
- Flange Feature:Mating Side, Female Screwlock (4-40)
- Termination:Solder
- Shell Material, Finish:Steel, Tin Plated
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):6A
- Backset Spacing:0.318" (8.08mm)
- Features:Ground Strap
