749798-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB HD PLUG 15P VERT SLDR
- CategoryD-Sub Connectors
- Datasheet 749798-1 Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:AMPLIMITE HD-22
- Package:Tray
- Part Status:Obsolete
- Connector Style:D-Sub, High Density
- Connector Type:Plug, Male Pins
- Number of Positions:15
- Number of Rows:3
- Mounting Type:Through Hole
- Shell Size, Connector Layout:1 (DE, E) High Density
- Contact Type:Signal
- Flange Feature:Housing/Shell (4-40)
- Termination:Solder
- Shell Material, Finish:Steel, Nickel Plated
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):1.5A
- Backset Spacing:-
- Features:Grounding Indents
