MLG0603S8N2JT000
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 8.2NH 200MA 700 MOHM
- CategoryFixed Inductors
- Datasheet MLG0603S8N2JT000 Datasheet
-
ECAD Model
- Share
In Stock: 33,312
Can ship immediately
Pricing:
- 1$0.26
- 15,000$0.08493
- 30,000$0.08228
- 75,000$0.07963
- 105,000$0.07697
Quote It
Technical Details
- Series:MLG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ceramic, Non-Magnetic
- Inductance:8.2 nH
- Tolerance:±5%
- Current Rating (Amps):200 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):700mOhm Max
- Q @ Freq:5 @ 100MHz
- Frequency - Self Resonant:3.8GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0201 (0603 Metric)
- Supplier Device Package:0201 (0603 Metric)
- Size / Dimension:0.024" L x 0.012" W (0.60mm x 0.30mm)
- Height - Seated (Max):0.013" (0.33mm)
