P0751.222NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 6.1A 15 MOHM SMD
- CategoryFixed Inductors
- Datasheet P0751.222NLT Datasheet
-
ECAD Model
- Share
In Stock: 10,930
Can ship immediately
Pricing:
- 1$1.05
- 800$0.476
- 1,600$0.448
- 4,000$0.434
- 5,600$0.42
- 20,000$0.406
Quote It
Technical Details
- Series:P0751NL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):6.1 A
- Current - Saturation (Isat):7A
- Shielding:Unshielded
- DC Resistance (DCR):15mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.510" L x 0.370" W (12.95mm x 9.40mm)
- Height - Seated (Max):0.215" (5.46mm)
