7443091120
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.2UH 34A 0.42 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 575
Can ship immediately
Pricing:
- 1$2.82
Quote It
Technical Details
- Series:WE-HCM
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Manganese Zinc Ferrite (MnZn)
- Inductance:1.2 µH
- Tolerance:±20%
- Current Rating (Amps):34 A
- Current - Saturation (Isat):36A
- Shielding:Shielded
- DC Resistance (DCR):0.42mOhm
- Q @ Freq:-
- Frequency - Self Resonant:16MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:1411
- Size / Dimension:0.571" L x 0.531" W (14.50mm x 13.50mm)
- Height - Seated (Max):0.421" (10.70mm)
