M27/370-25
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 1.3A 208 MOHM
- CategoryFixed Inductors
- Datasheet M27/370-25 Datasheet
-
ECAD Model
- Share
In Stock: 1,113
Can ship immediately
Pricing:
- 1$6.85
- 480$2.67921
- 960$2.4428
- 1,440$2.364
- 3,360$2.2852
Quote It
Technical Details
- Series:Military, MIL-PRF-27/370, MIL8532
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±15%
- Current Rating (Amps):1.3 A
- Current - Saturation (Isat):640mA
- Shielding:Unshielded
- DC Resistance (DCR):208mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 130°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.880" L x 0.330" W (22.35mm x 8.38mm)
- Height - Seated (Max):0.286" (7.26mm)
