DC780R-224K
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 2.8A 150 MOHM TH
- CategoryFixed Inductors
- Datasheet DC780R-224K Datasheet
-
ECAD Model
- Share
In Stock: 357
Can ship immediately
Pricing:
- 1$6.82
- 10$6.19949
- 25$5.57943
- 50$4.46363
- 100$4.21565
- 250$3.96767
- 500$3.84368
- 1,000$3.59571
Quote It
Technical Details
- Series:DC780R
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±10%
- Current Rating (Amps):2.8 A
- Current - Saturation (Isat):7.4A
- Shielding:Unshielded
- DC Resistance (DCR):150mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.772" Dia (19.60mm)
- Height - Seated (Max):0.831" (21.10mm)
