CI160808-10NJ
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10NH 300MA 350MOHM SMD
- CategoryFixed Inductors
- Datasheet CI160808-10NJ Datasheet
-
ECAD Model
- Share
In Stock: 5,790
Can ship immediately
Pricing:
- 1$0.1
- 4,000$0.02295
- 8,000$0.02168
- 12,000$0.0204
- 28,000$0.01995
Quote It
Technical Details
- Series:CI160808
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Type:Multilayer
- Material - Core:Ceramic
- Inductance:10 nH
- Tolerance:±5%
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):350mOhm Max
- Q @ Freq:10 @ 100MHz
- Frequency - Self Resonant:1.8GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.063" L x 0.031" W (1.60mm x 0.80mm)
- Height - Seated (Max):0.037" (0.95mm)
