BWCS002928214R7G00
Chilisin Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 260MA 4OHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 3,110
Can ship immediately
Pricing:
- 1$0.13
Quote It
Technical Details
- Series:BWCS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:4.7 µH
- Tolerance:±2%
- Current Rating (Amps):260 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):4Ohm Max
- Q @ Freq:20 @ 25MHz
- Frequency - Self Resonant:90MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:7.9 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:1411
- Size / Dimension:0.115" L x 0.110" W (2.92mm x 2.79mm)
- Height - Seated (Max):0.083" (2.10mm)
