LQH44PH6R8MPRL
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 1.5A 120 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 4,914
Can ship immediately
Pricing:
- 1$0.37
Quote It
Technical Details
- Series:LQH32
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):1.5 A
- Current - Saturation (Isat):1.85A
- Shielding:Shielded
- DC Resistance (DCR):120mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:30MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height - Seated (Max):0.071" (1.80mm)
