SDR7030-471K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470UH 220MA 2.8OHM SMD
- CategoryFixed Inductors
- Datasheet SDR7030-471K Datasheet
-
ECAD Model
- Share
In Stock: 1,656
Can ship immediately
Pricing:
- 1$0.88
- 1,500$0.289
- 3,000$0.272
Quote It
Technical Details
- Series:SDR7030
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:470 µH
- Tolerance:±10%
- Current Rating (Amps):220 mA
- Current - Saturation (Isat):230mA
- Shielding:Unshielded
- DC Resistance (DCR):2.8Ohm Max
- Q @ Freq:30 @ 796kHz
- Frequency - Self Resonant:6MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.276" L x 0.276" W (7.00mm x 7.00mm)
- Height - Seated (Max):0.130" (3.30mm)
