AMDLA4012S-1R0MT
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIND 1UH 5.2A 43MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 4,113
Can ship immediately
Pricing:
- 1$0.89
Quote It
Technical Details
- Series:AMDLA4012S
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:Metal
- Inductance:1 µH
- Tolerance:±20%
- Current Rating (Amps):5.2 A
- Current - Saturation (Isat):7.8A
- Shielding:Shielded
- DC Resistance (DCR):43mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.173" L x 0.157" W (4.40mm x 4.00mm)
- Height - Seated (Max):0.047" (1.20mm)
