SRP3020C-6R8M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 1.6A 300 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 3,282
Can ship immediately
Pricing:
- 1$0.94
Quote It
Technical Details
- Series:SRP3020C
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Metal
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):1.6 A
- Current - Saturation (Isat):1.8A
- Shielding:Shielded
- DC Resistance (DCR):300mOhm Max
- Q @ Freq:10 @ 100kHz
- Frequency - Self Resonant:27MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.138" L x 0.126" W (3.50mm x 3.20mm)
- Height - Seated (Max):0.079" (2.00mm)
