SRP0420-R68K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680NH 9.3A 13.2 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,966
Can ship immediately
Pricing:
- 1$0.98
Quote It
Technical Details
- Series:SRP0420
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Metal
- Inductance:680 nH
- Tolerance:±10%
- Current Rating (Amps):9.3 A
- Current - Saturation (Isat):10.5A
- Shielding:Shielded
- DC Resistance (DCR):13.2mOhm Max
- Q @ Freq:11 @ 25.2MHz
- Frequency - Self Resonant:64MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.173" L x 0.161" W (4.40mm x 4.10mm)
- Height - Seated (Max):0.079" (2.00mm)
