SRP0615-4R7K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 4.3A 62 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,431
Can ship immediately
Pricing:
- 1$1.08
Quote It
Technical Details
- Series:SRP0615
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Metal
- Inductance:4.7 µH
- Tolerance:±10%
- Current Rating (Amps):4.3 A
- Current - Saturation (Isat):6A
- Shielding:Shielded
- DC Resistance (DCR):62mOhm Max
- Q @ Freq:33 @ 7.96MHz
- Frequency - Self Resonant:16MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.280" L x 0.264" W (7.10mm x 6.70mm)
- Height - Seated (Max):0.059" (1.50mm)
