CMLE105T-100MS
Delta Electronics- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 7.6A 23 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,191
Can ship immediately
Pricing:
- 1$1.58
Quote It
Technical Details
- Series:CMLE105T
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Metal
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):7.6 A
- Current - Saturation (Isat):11A
- Shielding:Shielded
- DC Resistance (DCR):23mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.427" L x 0.394" W (10.85mm x 10.00mm)
- Height - Seated (Max):0.197" (5.00mm)
