IHLP6767GZER150M11
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 14A 14.4 MOHM SMD
- CategoryFixed Inductors
- Datasheet IHLP6767GZER150M11 Datasheet
-
ECAD Model
- Share
In Stock: 6,395
Can ship immediately
Pricing:
- 1$3.73
- 200$3.06
- 400$2.89
- 600$2.72
- 1,000$2.55
Quote It
Technical Details
- Series:IHLP-6767GZ-11
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):14 A
- Current - Saturation (Isat):12A
- Shielding:Shielded
- DC Resistance (DCR):14.4mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:7.5MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.675" L x 0.675" W (17.15mm x 17.15mm)
- Height - Seated (Max):0.276" (7.00mm)
