B82559B5332A016
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 25A 2.2 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 524
Can ship immediately
Pricing:
- 1$5.4
Quote It
Technical Details
- Series:ERU16 - Flat Wire Inductor
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±10%
- Current Rating (Amps):25 A
- Current - Saturation (Isat):30.9A
- Shielding:Shielded
- DC Resistance (DCR):2.2mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard, 3 Lead
- Supplier Device Package:-
- Size / Dimension:0.681" L x 0.650" W (17.30mm x 16.50mm)
- Height - Seated (Max):0.407" (10.35mm)
