2300LL-220-H-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 17.7A 5 MOHM TH
- CategoryFixed Inductors
- Datasheet 2300LL-220-H-RC Datasheet
-
ECAD Model
- Share
In Stock: 645
Can ship immediately
Pricing:
- 1$5.25
- 480$2.91725
Quote It
Technical Details
- Series:2300LL
- Package:Bulk
- Part Status:Active
- Type:Toroidal
- Material - Core:Sendust
- Inductance:22 µH
- Tolerance:±15%
- Current Rating (Amps):17.7 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Horizontal (Open)
- Supplier Device Package:-
- Size / Dimension:1.280" Dia (32.51mm)
- Height - Seated (Max):0.650" (16.51mm)
