ELJ-PF2N2DF
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2NH 1.9A 40 MOHM SMD
- CategoryFixed Inductors
- Datasheet ELJ-PF2N2DF Datasheet
-
ECAD Model
- Share
In Stock: 5,779
Can ship immediately
Pricing:
- 1$0.14
- 10,000$0.04833
- 30,000$0.04677
- 50,000$0.04522
Quote It
Technical Details
- Series:PF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:2.2 nH
- Tolerance:±0.3nH
- Current Rating (Amps):1.9 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):40mOhm Max
- Q @ Freq:7 @ 100MHz
- Frequency - Self Resonant:5.3GHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
- Height - Seated (Max):0.022" (0.55mm)
