LQM18NN1R8K00D
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.8UH 25MA 950 MOHM
- CategoryFixed Inductors
- Datasheet LQM18NN1R8K00D Datasheet
-
ECAD Model
- Share
In Stock: 3,952
Can ship immediately
Pricing:
- 1$0.23
- 4,000$0.08186
- 8,000$0.07731
- 12,000$0.07276
- 28,000$0.0705
- 100,000$0.06595
Quote It
Technical Details
- Series:LQM18
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:1.8 µH
- Tolerance:±10%
- Current Rating (Amps):25 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):950mOhm Max
- Q @ Freq:35 @ 10MHz
- Frequency - Self Resonant:55MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:10 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.063" L x 0.031" W (1.60mm x 0.80mm)
- Height - Seated (Max):0.037" (0.95mm)
