MLF2012DR12MTD25
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 120NH 300MA 200 MOHM
- CategoryFixed Inductors
- Datasheet MLF2012DR12MTD25 Datasheet
-
ECAD Model
- Share
In Stock: 2,714
Can ship immediately
Pricing:
- 1$0.26
- 4,000$0.0936
- 8,000$0.0884
- 12,000$0.0832
- 28,000$0.0806
- 100,000$0.0754
Quote It
Technical Details
- Series:MLF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:120 nH
- Tolerance:±20%
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):200mOhm Max
- Q @ Freq:20 @ 25MHz
- Frequency - Self Resonant:360MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:25 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.041" (1.05mm)
