B78108E1223K000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.3A 350 MOHM TH
- CategoryFixed Inductors
- Datasheet B78108E1223K000 Datasheet
-
ECAD Model
- Share
In Stock: 2,775
Can ship immediately
Pricing:
- 1$0.44
- 5,000$0.156
- 10,000$0.15113
- 25,000$0.14625
- 50,000$0.14138
Quote It
Technical Details
- Series:BC+
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±10%
- Current Rating (Amps):1.3 A
- Current - Saturation (Isat):1.25A
- Shielding:Unshielded
- DC Resistance (DCR):350mOhm Max
- Q @ Freq:40 @ 796kHz
- Frequency - Self Resonant:12MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.157" Dia x 0.374" L (4.00mm x 9.50mm)
- Height - Seated (Max):-
