84223C

Technical Details

• Series:8400
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:-
• Inductance:22 µH
• Tolerance:±10%
• Current Rating (Amps):600 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):600mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:-
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.177" L x 0.130" W (4.50mm x 3.30mm)
• Height - Seated (Max):0.114" (2.90mm)
