74479776233A
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 1.25A 150 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 3,063
Can ship immediately
Pricing:
- 1$0.67
Quote It
Technical Details
- Series:WE-PMI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:-
- Inductance:3.3 µH
- Tolerance:±20%
- Current Rating (Amps):1.25 A
- Current - Saturation (Isat):330mA
- Shielding:Shielded
- DC Resistance (DCR):150mOhm Max
- Q @ Freq:25 @ 1MHz
- Frequency - Self Resonant:40MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0806 (2016 Metric)
- Supplier Device Package:0806
- Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max):0.039" (1.00mm)
