7440329220
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 250MA 923 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,115
Can ship immediately
Pricing:
- 1$0.68
- 2,000$0.444
Quote It
Technical Details
- Series:WE-LQ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±10%
- Current Rating (Amps):250 mA
- Current - Saturation (Isat):400mA
- Shielding:Unshielded
- DC Resistance (DCR):923mOhm Max
- Q @ Freq:35 @ 1MHz
- Frequency - Self Resonant:19MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1210 (3225 Metric)
- Supplier Device Package:1210
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.067" (1.70mm)
