74404054471
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470UH 350MA 2.95 OHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,111
Can ship immediately
Pricing:
- 1$1.12
Quote It
Technical Details
- Series:WE-LQS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:470 µH
- Tolerance:±20%
- Current Rating (Amps):350 mA
- Current - Saturation (Isat):400mA
- Shielding:Semi-Shielded
- DC Resistance (DCR):2.95Ohm
- Q @ Freq:-
- Frequency - Self Resonant:2.5MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:5040
- Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
- Height - Seated (Max):0.157" (4.00mm)
