SRR1806-100M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 4A 33 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1806-100M Datasheet
-
ECAD Model
- Share
In Stock: 1,361
Can ship immediately
Pricing:
- 1$1.19
- 250$0.55336
- 500$0.4743
- 750$0.44795
- 1,250$0.4216
- 2,500$0.4123
Quote It
Technical Details
- Series:SRR1806
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):4 A
- Current - Saturation (Isat):8.2A
- Shielding:Shielded
- DC Resistance (DCR):33mOhm
- Q @ Freq:56 @ 2.52MHz
- Frequency - Self Resonant:19MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.720" L x 0.551" W (18.30mm x 14.00mm)
- Height - Seated (Max):0.280" (7.10mm)
