NS12555T220MN
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 3.81A 35.64 MOHM
- CategoryFixed Inductors
- Datasheet NS12555T220MN Datasheet
-
ECAD Model
- Share
In Stock: 1,476
Can ship immediately
Pricing:
- 1$1.24
- 2,000$0.5648
Quote It
Technical Details
- Series:NS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):3.81 A
- Current - Saturation (Isat):3.2A
- Shielding:Shielded
- DC Resistance (DCR):35.64mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:13.2MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.230" (5.85mm)
